Yamaha TT-R125LWE

125cc 4-stroke engine

Driven by a 125 cc 4-stroke engine, the TT-R125LWE deliver plenty of smooth power for spirited off-road riding. Being air-cooled, this punchy little engine is relatively simple to maintain, and with a 5-speed gearbox and manual clutch, both models prepare the rider for the day when they move up to a full-sized motorcycle.

Long travel suspension

Check out the compact steel frame and rugged suspension systems and you can see that this is a seriously capable off-road motorcycle. The sturdy front forks offer an impressive 180 mm of wheel travel, while the link-type rear suspension gives 168 mm of movement, allowing the TT-R125LWE to handle some seriously tough terrain.

YZ-inspired bodywork

The stunning bodywork on the TT-R125LWE was inspired by our MXGP-winning YZ bikes. Made from specially-developed polypropylene that combines low weight with high strength, the fenders, tank panels and side panels are built to handle some tough treatment.

Smooth stopping power

To handle the TT-R125LWE's perky performance, the bike has an efficient 220 mm diameter front disc brake that allows the rider to reduce speed with minimum effort. A 110 mm drum brake delivers smooth stopping power at the rear end, and for good traction the TT-R125LWE runs on a chunky, 90-section rear tyre.

Large diameter wheels

To complement the rugged chassis and long-travel suspension systems, the TT-R125LWE is equipped with a 19-inch diameter front wheel and a 16-inch diameter rear wheel. Their large diameter gives greater ground clearance, and enables the TT-R125LWE to handle uneven off-road surfaces for a more enjoyable ride.

Engine

Engine Type: Air-cooled, 4-stroke, SOHC, 2-valve

Displacement (cc): 124.0

Bore x Stroke (mm): 54.0 x 54.0

Compression Ratio: 10.0 : 1

Lubrication System: Wet sump

Fuel Management: VM20 x 1

Ignition: CDI

Starter System: Electric and Kick

Fuel Tank Capacity (L): 6.0

Final Transmission: Chain

Transmission: Constant mesh 5-speed

Chassis

Frame Type: Diamond

Suspension Front: Telescopic forks, 180mm travel

Suspension Rear: Swingarm (link suspension), 168mm travel

Brakes Front: Hydraulic single disc, 220mm

Brakes Rear: Drum

Tyres Front: 70/100-19 42M Tube type

Tyres Rear: 90/100-16 52M Tube type

Dimensions

Length (mm): 1885

Width (mm): 795

Height (mm): 1085

Seat Height (mm): 805

Wheelbase (mm): 1270

Ground Clearance (mm): 295

Wet Weight (kg): 90
