Yamaha YZ250

Yamaha’s race-tested YZ250 two-stroke is already known for its fast, powerful engine, plush suspension, class-leading handling and rider friendly character.

Its 249cc liquid-cooled YPVS-equipped reed-valve-inducted two-stroke engine is lightweight, compact and fun, with an incredibly wide, hard-hitting powerband; all housed within a carefully engineered, advanced aluminium frame for maximum track performance.

YZ250 2-stroke: The legend lives on!

250cc YPVS 2-Stroke Engine

250cc YPVS 2-Stroke Engine

The outstanding 250cc 2-stroke engine delivers instant power on demand. Equipped with a torque-boosting YPVS (Yamaha Power Valve System) and driving through a 5-speed transmission, this compact and lightweight unit loves to race hard.

Aggressive YZ Styling

Aggressive YZ Styling

Race-inspired styling - from the sharp embedded graphics, to the aggressive bodywork including front and rear fenders, blacked-out radiator shrouds and number plates, to the smaller details like fork guards, rear brake disc and caliper protectors, and wide footpegs - spotlights the YZ250's extensive two-stroke racing pedigree from every angle.

Industry-Leading KB Suspension

Industry-Leading KB Suspension

The fully adjustable KYB® 48mm forks feature the Speed Sensitive System which uses piston speed to control the damping force for super-precise handling, superb bump absorption and 300mm of suspension travel.

Lightweight Aluminium Chassis

Lightweight Aluminium Chassis

A carefully engineered, advanced aluminium frame and swingarm give the YZ250 the best handling in the 250cc class, while the removable aluminium rear subframe is constructed of square-section tubing for reduced weight.

Powerful Braking System

Powerful Braking System

The high performance braking system features a 270mm front rotor, 240mm rear rotor, large front pistons and rigid calipers, all combining to provide exceptional braking power and feel.

Race-bred Ergonomics

Race-bred Ergonomics

Complete with an aluminium handlebar, two-position adjustable handlebar clamp, wide footpegs, gripper seat and adjustable clutch lever with works-style cable adjuster, the YZ250 is competition-ready straight out of the crate.
Make an Enquiry View More Models

Technical Specifications

Yamaha YZ250 Specs

Engine

Engine Type: Liquid-cooled, 2-stroke, reed-valve with YPVS

Displacement (cc): 249.0

Bore x Stroke (mm): 66.4 x 72.0

Compression Ratio: 8.9 - 10.6 : 1

Lubrication System: Premix

Fuel Management: PWK38S

Ignition: CDI

Starter System: Kick

Fuel Tank Capacity (L): 7.0

Final Transmission: Chain

Transmission: Constant mesh 5-speed

Chassis

Frame Type: Aluminium controlled filled semi double cradle

Suspension Front: Telescopic forks, 300mm travel

Suspension Rear: Swingarm (link suspension), 315mm travel

Brakes Front: Hydraulic single disc, 270mm

Brakes Rear: Hydraulic single disc, 240mm

Tyres Front: 80/100-21 Dunlop Geomax MX33F

Tyres Rear: 110/90-19 Dunlop Geomax MX33

Dimensions

Length (mm): 2185

Width (mm): 825

Height (mm): 1290

Seat Height (mm): 975

Wheelbase (mm): 1485

Ground Clearance (mm): 360

Wet Weight (kg): 103

Colours

Colours and trims displayed here are a guide only and may vary from actual colours due to the display process.

  1. Team Yamaha Blue
