Yamaha YZ250FSP

Class-leading four-stroke performance wrapped in iconic heritage YZ style, the YZ250F 50th Anniversary Edition draws its inspiration from 1990s-era Yamaha two-stroke motocrossers to honor 50 years of Yamaha off-road innovation.

Featuring a high-spec piston, aggressive cam profiles and forward positioned intake cylinder head layout, the YZ250F's advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque. New for 2024, a more efficient intake path and revised ECU settings results in even more mid- to high-end power.

The aluminium bilateral beam frame has been completely redesigned based on the flagship YZ450F and provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.

Advanced 250cc 4-stroke Engine

Advanced 250cc 4-stroke Engine

The YZ250F's liquid-cooled, DOHC 4-valve, fuel-injected powerplant features a forward-positioned straight downdraft intake with symmetrical intake ports, high- spec piston and aggressive cam profiles. The advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque. New for 2024, a more efficient intake path and revised ECU settings results in even more mid- to high-end power.

New Aluminium Bilateral Beam Frame

New Aluminium Bilateral Beam Frame

A completely redesigned aluminium bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.

Yamaha Power Tuner App

Yamaha Power Tuner App

Like having factory team support in your pocket, Yamaha's groundbreaking Power Tuner App is revised to be even more user- friendly. New features include an intuitive "Simple Tuning" slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with helpful engine and suspension tuning guides.

Revised Suspension Settings

Revised Suspension Settings

Class leading, fully adjustable KB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. New for 2024, the fork now includes hand- adiustable knob for toolless compression adjustment. Linkage-type rear suspension features a KYB® shock with revised settings to provide less pitch on corner entry/exit for improved stability.

New Air Intake

New Air Intake

Optimised intake path draws air from under the side covers and seat allowing for a lighter, slimmer and more compact body. This redesign allows radiator shrouds to be slimmer and the airbox cover to be lower and more narrow. The more efficient intake path also boosts mid- to high-rpm engine performance.

New Traction Control & Launch Control

New Traction Control & Launch Control

The all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction. Three levels can be selected: HIGH, LOW or OFF. The updated Launch Control System now features an rpm limiter which can be adjusted in 500 rpm increments between 6,000 pm and 14,000 rpm for optimised launches when the gate drops. Both systems are controlled through the Yamaha Power Tuner App.

Adjustable Engine Maps

Adjustable Engine Maps

New handlebar-mounted switch allows on- the-fly selection between two preloaded engine maps with the push of a button, making it easy to make immediate adjustments to changing track or weather conditions. Maps are loaded and configured within the Power Tuner App.

Strong, Lightweight Wheels

Strong, Lightweight Wheels

Careful computer-aided refinement of each wheel's cross-sectional profile shaves valuable weight without sacrificing durability. Unique three-cross-spoke pattern on the rear wheel improves impact absorption and overall feel.
Make an Enquiry View More Models

Technical Specifications

Yamaha YZ250FSP Specs

Engine

Engine Type: Liquid-cooled, 4-stroke, DOHC, 4-valve

Displacement (cc): 250.0

Bore x Stroke (mm): 77.0x 53.6

Compression Ratio: 13.8 : 1

Lubrication System: Wet sump

Fuel Management: Fuel Injection

Ignition: TCI

Starter System: Electric

Fuel Tank Capacity (L): 6.1

Final Transmission: Chain

Transmission: Constant mesh 5-speed

Chassis

Frame Type: Bilateral beam

Suspension Front: Telescopic forks, 310mm travel

Suspension Rear: Swingarm (link suspension), 312mm travel

Brakes Front: Hydraulic single discs, 270mm

Brakes Rear: Hydraulic single disc, 240mm

Tyres Front: 80/100-21 Dunlop Geomax MX33F

Tyres Rear: 110/90-19 Dunlop Geomax MX33

Dimensions

Length (mm): 2180

Width (mm): 825

Height (mm): 1275

Seat Height (mm): 970

Wheelbase (mm): 1475

Ground Clearance (mm): 350

Wet Weight (kg): 105

Colours

Colours and trims displayed here are a guide only and may vary from actual colours due to the display process.

  1. 50th Anniversary
